Key Features & Benefits:

✅ Superior Strength & Durability

• Изготовлено из SUS304 нержавеющая сталь, ensuring maximum corrosion resistance и long-lasting performance in all weather conditions.
• Guaranteed for 10 years with a lifespan of up to 25 years.

✅ Effortless Installation & Time-Saving Design

• Pre-assembled components eliminate complex assembly steps, reducing labor costs and installation time.
• Совместимость с PVMOUNTS solar rails and D-modules, allowing for a seamless setup using just a single hex key and basic tools.
• No drilling or welding required—quick and secure attachment to the wooden batten beneath the tile.

✅ Adjustable & Universal Compatibility

• Flexible, slotted design allows easy length and position adjustments, accommodating various tile types and bolt connections.
• Works with all major framed solar panel brands, making it a universal racking system.
• No need to pierce the tile surface, ensuring superior waterproof performance and maintaining roof integrity.

✅ Customized Solutions for Any Roof Type

• Custom-made tile hooks available based on tile specifications, ensuring a perfect fit for any flat, curved, or 90-degree tile roof.
• Tailored solutions for wholesalers, B2B customers, B2C platforms, brand manufacturers, and solar construction installers.

Tile Roof Mounting System Components Bom list,

Ideal for:

• Residential and commercial solar PV installations on tile roofs.
• EPC contractor, Wholesalers and installers seeking a high-quality, adaptable solution for photovoltaic mounting systems.

🔧 Choose PVMOUNTS for precision, reliability, and seamless solar mounting. Contact us today for customized solutions tailored to your project needs!

🔗 Keywords:

Tile roof hook for solar mounting, Solar Flat Tile Roof Hook, Roof Hooks For Photovoltaics On Roofs With Tile Roofing, Solar Panel Roof Tile Hooks, SUS304 tile roof hook, stainless steel roof hook, stainless steel 304 roof hook, tile roof hook, customized tile roof hook, tile roof attachment, 90-degree tile roof hook, curved tile roof hook.

Экскурсия на завод по производству систем крепления солнечных панелей

Installing a tile roof hook for a solar mounting system requires careful handling to ensure a secure and waterproof installation. Here’s a step-by-step guide:

Tools & Materials Required:

• Tile roof hooks (SUS304 stainless steel recommended)
• Wood screws or lag bolts
• Drill with appropriate drill bits
• Wrench or socket set
• Sealant (optional for extra waterproofing)
• Measuring tape
• Chalk line

Installation Steps:

• Use a stud finder or tap the roof surface to identify the wooden rafters beneath the tiles.
• Mark the rafter positions using a chalk line.

2. Carefully Remove the Tile

• Gently lift and slide out the designated roof tile using a pry bar or similar tool.
• Be cautious not to break the tile.

3. Position the Roof Hook

• Align the roof hook directly over the rafter for maximum strength.
• Ensure the hook extends outwards where the solar rail will be mounted.

4. Secure the Hook to the Rafter

• Drill pilot holes into the rafter to prevent wood splitting.
• Fasten the hook using stainless steel wood screws or lag bolts.
• Ensure the hook is firmly secured and does not move.

5. Reinstall the Tile

• Carefully place the removed tile back over the installed hook.
• If necessary, slightly modify or trim the underside of the tile to fit around the hook.
• Ensure the tile sits properly to maintain waterproofing.

6. Install the Mounting Rails

• Attach aluminum mounting rails to the roof hooks using bolts.
• Check for alignment and adjust as needed.

7. Fasten Solar Modules

• Use mid clamps и end clamps to secure solar panels onto the rails.
• Tighten all bolts securely.

8. Final Inspection

• Ensure all components are properly tightened.
• Check for any gaps or loose tiles.
• Apply additional sealant if needed for extra waterproofing.

Additional Tips:

✔ Use stainless steel fasteners to prevent corrosion.
✔ Space the hooks evenly according to engineering load calculations.
✔ Ensure proper drainage by avoiding blockage of water flow under the tiles.

Would you like a visual guide or installation video recommendations?We offer installation guide including images, instruction as well as videos to help our customer mount the system easily and fast.

One stop manufacturer specialized in solar mounting system and components for your solar mount projects.

PVMOUNTS has all kinds of solar mounting accessories designed for using on almost every roof and ground with excellent compatibility. Customized order is acceptable.

We can produce different solar panel mounted components including but not limited in:

• Рельсы
• Крючки
• L-Feet
• Винты заземления
• Зажимы для стоячих швов
• Mid Clamp & End Clamp
• Заземляющий наконечник
• Grounding Clip
• Cable Clip
• и многое другое
